RE: Regarding import of external content, some info on our "Form Parts" feature

Hi Philip,

From the "putting your money where your mouth is" perspective, I'd have no
choice but to concur since we built the Form Parts feature in a framework
(i.e. Designer tooling/transformational) way rather than as a language
(i.e. run-time) feature.

I think the working group generally agrees that run-time fix ups are
daunting.  I imagine Erik/Orbeon would have more to say about it.

But this takes us back to the simpler issue of model/@src.  The
communication started from a drill down in which many of us, including
you, have indicated we want something like model/@src, but when we look
under the covers we become hard pressed to identify a significant
advantage that it provides, and it isn't until you do something like
either Form Parts or Orbeon's XBL-based components that you get a
significant advantage over what we have now.

So, the question is, what could you do with model/@src that can't already
be done with, say, XInclude?

FWIW, I am especially worried about ID fix-ups given the number of places
where we can now obtain the ID from data.  I think the idea is just plain
not going to work out due to the case subelement of toggle, the control
subelement of setfocus, etc.

John M. Boyer, Ph.D.
STSM, Lotus Forms
Workplace, Portal and Collaboration Software
IBM Victoria Software Lab


Blog RSS feed:

Philip Fennell <>
John Boyer/CanWest/IBM@IBMCA, Nick Van den Bleeken
"" <>
04/15/2010 03:10 PM
RE: Regarding import of external content, some info on our "Form  Parts"

With respect to the generalized component import issue, is there not a
risk that we are blurring the line between XForms language features and
XForms frameworks features. As a language, XForms is rather odd in that it
comes in two separate, but dependant, parts and uses a host document to
support them both, a kind of three-way symbiotic relationship. I can see
how re-usable form components are a good idea in and of themselves but the
whole business of defining an import that can/should only be declared in
one place but must have an outcome in two places is rather, if not too,
complex for what is otherwise a straight forward and elegant language.
The concept of Xf:model/@src is a good idea and one that I have wished for
in the past.
Where I’m currently generating XForms from XML Schema, I’m using XProc to
orchestrate the transformations and will probably end up with a step that
delivers the model and view components on separate ‘model’ and ‘view’
result ports, respectively, and then use subsequent steps to insert those
results into a host application XHTML document. That is probably why I see
the multi-destination import as a framework feature more than a language
feature because it seem easier to solve that way. The amount of ‘fix-up’
required to do the same amount of work automatically would be quite
daunting and would probably render any additional bindings after the act
of importation impossible to manage/work as you’d have no idea what the
fix-up has done to your model, instance and bind IDs.
Philip Fennell
Mark Logic Corporation
Mobile: +44 (0)7824 830 866

From: [] On
Behalf Of John Boyer
Sent: Monday, April 12, 2010 10:01 PM
To: Nick Van den Bleeken
Subject: RE: Regarding import of external content, some info on our "Form
Parts" feature

Hi Nick,

Yes I agree that we are also essentially saying that simple external model
is not enough to solve all of the problems faced by our customers, who
seem to need a more generalized "custom subform component" capability.

Still, external model seemed like a step in the right direction, ignoring
what we currently do with "Form Parts", even though it doesn't solve the
problem of combining UI and model declarations into a single reusable
component.  It seemed like we might at least be able to get some
instances, submissions and binds that would enable importation of web
service definitions, for example.

In this regard, it makes sense to talk about "Form Parts" as another
instance-- not the only one-- of a technology that would be both capable
of and *likely* to be used as a substitute for simple external model

The fact that both "Form Parts" at design time or XBL at run-time could
also be used to create generalized custom components does not detract from
the fact that we've seen two categorically different approaches that have
arisen that would both benefit from having the one standardized way of
doing the import, even if that import did not scale up to the case of
generalized custom components.  Whether it has enough value or not,
without also getting generalized custom components, is of course up to the

Meanwhile, the reason why a simple external model import cannot scale up
to generalized custom components seems to be clear also, by looking at
both the XBL approach and the "Form Parts" approach.  In both cases, two
different techniques are used to ensure that both UI and model content are
added to the importing form.   In both cases, the exact point of injection
into the UI is, and has to be, identified.  The injection point into the
model does not seem to be so important and is not identifed by either
approach.  Any kind of "model import" that turned into "subform import"
would need to add a way to indicate where in the UI should be injected the
UI portion of the subform.

John M. Boyer, Ph.D.
STSM, Lotus Forms
Workplace, Portal and Collaboration Software
IBM Victoria Software Lab


Blog RSS feed:

Nick Van den Bleeken <>
John Boyer/CanWest/IBM@IBMCA, "" <>
04/09/2010 12:13 AM
RE: Regarding import of external content, some info on our "Form Parts"

Correct me if I’m wrong, but I see this as custom components. There is a
bit of tweak that the ‘components’ are resolved at runtime, but this can
be just how your implementation resolves the components (it only looks in
the ‘archive’ created for the form document, the document itself could
also be seen as an ‘archive’ if you want, you can refer inside the
For me it seems very close to what is solved in Orbeon by their custom
components implementation based on XBL. Erik is better placed to elaborate
on this, but what I see are: a binding site in the form (both data and
UI), local models, probably some kind of communication between the main
form and the ‘sub form’ using events (you didn’t spell this out, but I
think you will have it or will need it in the future). Orbeon’s solution
is also a bit more generic that it doesn’t acts as a single group, they
can have multiple data bindings to the custom control (again, Erik correct
me if I’m wrong).
We are hitting more and more cases in our company that require a ‘custom
component’/’reusable sub-form’ solution. I believe that this is something
that should have a high importance on our roadmap, but I don’t think that
external models and ‘custom components’/’reusable sub-forms’ are the same
thing. External models should be the smaller feature of the two.
Nick Van den Bleeken
R&D Manager
Phone: +32 3 821 01 70
Office Fax: +32 3 821 01 71
Linked in
From: [] On
Behalf Of John Boyer
Sent: vrijdag 9 april 2010 2:54
Subject: Regarding import of external content, some info on our "Form
Parts" feature

Dear Forms WG,

As part of the work of determining how to approach the import of external
content, I have been asked to provide some technical information on our
"Form Parts" feature, which is related in that it does call for
importation of XForms content into a larger XForms, but is not strictly
related to the simple use of a src attribute on model or otherwise.

The IBM Lotus Forms team is currently implementing a feature called "Form
Parts", and a fair bit of the functionality is currently available in our
latest "Tech Preview".

The "Form Parts" feature allows users of our Form Designer environment to
create reusable form fragments that may be consumed by any number of form
templates in a form collection.
The Design environment can understand any number of Form Parts, and the
form author can update any number of form parts before requested to update
the form templates that use the updated form parts.

The form templates themselves contain the content of each Form Part they
consume plus an indication of where that content came from.  The indicator
allows us to do the updating, but having the form part content in the form
template means that the form template is always ready to be published to
the web without a "compile" step.  In other words, the compile step is
loaded onto form part updates rather than as a prerequisite to someone
trying to use the form.  Furthermore, it should be clear that the form
template is always ready to be used by a run-time XForms processor without
it having to load externally referenced content.

In our solution, a "Form Part" can have multiple "components".  In our
Tech Preview, you get one component that logically maps to the content of
an xforms:group element.  In other words, the component is designed to
allow the form author to define a set of user interface elements that are
reusable in multiple forms.

When a form author drags and drops such a "Form Part" on the Design
canvas, they effectively get a copy of the user interface contained by the
main component of the Form Part.  By default, our Design environment
automatically generates the underlying XForms instance data model for a
form, so a data layer for this UI is automatically created.  However, the
design environment is also responsive to more advanced form authors that
have designed their own data layer, e.g. according to an XML Schema.  The
form part drag and drop opereration automatically brings up a design-time
dialog that allows the form author to create a mapping of the UI
components onto the existing data model in the form to which the Form Part
content is being added.  The form author can click OK without creating a
mapping, in which case a data instance for the UI is automatically
generated into the form as mentioned above.

The work we are currently undertaking on this "Form Parts" feature
recognizes that a form fundamentally has two components, the UI part and
the data model part.  So, we are currently enabling our Form Parts to have
a second component that contains xforms:model content.  Thus, when the
form authors drags and drops a form part onto the design canvas, the UI
component would be added by adding an xforms:group to the UI layer, and
any xfoms:binds or other model content would be added to the default
xforms:model of the form.  This allows us to have a reusable form part
that expresses both UI as well as constraints, calculates, etc on the data
collected by that UI.

So, in a way, this solution could be seen as another, perhaps easier, way
to deal with the larger problem of form composition.  At the run-time
level, we seem to always think about subforms and try to solve the problem
of data communication between a subform and the form that contains it. The
"Form Parts" solution instead does an injection of markup into two
non-continuous locations within a document.  In this way, it is also not
like an XInclude or the use of a simple src attribute.  Finally, by virtue
of being a Design time mechanism, issues related to ID conflicts are
sorted out before the form ever hits the run-time.

The downside of this approach is that it assumes a Design experience
distinct from the run-time, whereas the W3C track record on Design
environments rarely if ever gets beyond a text editor.

So, even if we were to have a run-time mechanism, my ideal world would be
a customized solution that could inject content into at least two
non-continuous parts of a form.  Furthermore, despite the fact that our
*current* system is based on the Design time, I do see value in moving
what we have into a run-time solution because I think it would help to
create more interesting "Interactive Web Documents".  But that is another
topic with prerequisite reading at [1].


John M. Boyer, Ph.D.
STSM, Lotus Forms
Workplace, Portal and Collaboration Software
IBM Victoria Software Lab


Blog RSS feed:

This message has been scanned for viruses and
dangerous content, and is believed to be clean.

Inventive Designers' Email Disclaimer:

This message has been scanned for viruses and
dangerous content, and is believed to be clean.

Received on Thursday, 15 April 2010 23:17:14 UTC
